MINI MIXER AMPLIFIER

Premium Mini Mixer Amplifier designed for professional audio distribution in residential, commercial, and public address systems. The ISH-FY-120W delivers powerful 120W RMS output with high-efficiency Class D amplification, ensuring stable performance, low heat generation, and energy-efficient operation. It supports multiple input sources including Bluetooth, USB, TF card, FM radio, microphone, and AUX inputs, making it a complete all-in-one audio solution. With support for both 100V/70V line systems and low-impedance 4–16Ω speakers, it offers maximum installation flexibility. Its compact aluminum design and intelligent protection system ensure long-term reliability and safe operation for continuous use.

Key Features

Product Type: Mini Mixer Amplifier
Brand: LINK
Model: ISH-FY-120W
Output Power: 120W RMS
Amplifier Type: Class D High-Efficiency Amplifier
Output Modes: 100V / 70V / 4–16Ω
Input Voltage: AC 100–240V ±10%, 50/60Hz
Power Consumption: 160W
Frequency Response: 60Hz – 18kHz (±3dB)
THD: <0.5% @ 1kHz
Signal-to-Noise Ratio: AUX >80dB, MIC >65dB
Tone Control: Bass ±10dB @ 100Hz, Treble ±10dB @ 10kHz
Inputs: 3× Microphone (MIC1, MIC2, Front MIC), 2× AUX
Media Support: Bluetooth, USB, TF Card, FM Radio
Phantom Power: Supported (2 Channels)
Display: LED 7-Digit Digital Display
Remote Control: Infrared Remote Included
Material: Aluminum Alloy Front Panel
Color: Black
Protection Functions: Short Circuit, DC Protection, Over-Temperature Protection
Dimensions: 63 × 215 × 285 mm
Performance: Stable Output, Multi-Source Audio Playback, Professional Sound Control
Application: Schools, Mosques, Offices, Restaurants, Retail Stores, Conference Rooms, and Public Address Systems

Note: Designed for professional audio amplification with multi-input support, Class D efficiency, and reliable protection systems for continuous operation.
